Modern Design Luxury Light Steel Frame Prefabricated House Villa Steel House Kits

Modern Design Luxury Light Steel Frame Prefabricated House Villa Steel House Kits

Linz House

 3 bedrooms  2 Bathroom  2 Living 2 Garage 389.2m²

Discover the perfect blend of spacious comfort, thoughtful design, and modern innovation with the Linz House, a stunning two-story single-family home designed for contemporary living. With a generous total area of 389.2 square meters, this model (DPBL-24-52) is engineered to provide an unparalleled living experience for you and your family.

Layout & Design:

Spacious and Intelligent Layout

Spanning a substantial 12.5m x 20.3m footprint, the Linz House maximizes every square meter with a logical and elegant floor plan.

Ground Floor – Designed for Living and Entertaining: Step through the entrance into a home designed for both daily life and hosting guests. The practical layout places the kitchen conveniently to the right, flowing seamlessly into the dining area—perfect for family meals and gatherings. Beyond this, the home opens up to not one, but two distinct living areas, offering ample space for relaxation, entertainment, and family time. A bathroom and a convenient two-car garage complete this level, ensuring functionality meets style.

First Floor – Dedicated to Rest and Recharge: The upper level is a private sanctuary dedicated to comfort and tranquility. It features three well-appointed bedrooms, including a master suite, providing peaceful retreats for everyone. An additional study or home office space offers a quiet environment for work or concentration, making the Linz House perfectly adapted for modern hybrid lifestyles.

Floorplan:

• Product parameters:



  Name:	Linz House
  Size:	12549 ×20288mm
  Ground floor area:	194.6sqm
  First Floor Area:	194.6sqm
  Total Area:	389.2sqm
  Model:	DPBL-25-48



Applications:

Hotel, House, Office, etc.

Product Description:

DeepBlue earthquake proof prefabricated bungalow is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers.
the materials are the following:
1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.
the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis: 89mm light gauge steel flooring chassis
4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, Pvc carpet, etc.
5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration
6. interior lining: 9m fiber cement board, water-proof, termite-proof, security and healthy
7. ceiling: 8mm Pvc ceiling panel
8. insulation: 89mm glass wool insulation with good soundproof performance.
9.windows: PVC sliding windows
10.exterior door: high-quality aluminum sliding windows
11.interior door: painted wood door
12.bathroom: shower, washbasin, toilet included
13. roofing: corrugated steel roofing with the gutter system
14. veranda deck: W.P.C veranda flooring.

Specifications:

ISO standard steel structure house .one or two also three floors available. fireproof, heat insulation, wind, and earthquake resistance. green, energy-saving. economically.

Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance: all the materials used can be fire-resistant.
5)Snow resistance: max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11)Installation: the average is one worker one day install one SQM.
12)Installation guide: dispatch engineer to guide on site.

Design code:

(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.

Resistant to various weather conditions, due to its light gauge steel framing system, DeepBlue Mobile Homes can resist winds up to 50m/s, 50cm snow loads as well withstand earthquakes due to its special steel structure technology.

The DeepBlue Mobile Houses manufacturing technology is truly a mature product characterized by flexibility and innovative design and solution.

Based on our patented foldable technology, transportation and erection can be done in a very simple and convenient way in order to save lots of time, energy, and unnecessary expenses.

Your first choice, Deepblue Prefabrica
